KEW 6516 Multifunction Tester - 12 in 1 with Bluetooth

DESCRIPTION

The KEW 6516/ KEW 6516BT Multi-Function tester has eight test functions in one instrument.

• Continuity test
• Insulation resistance test
• Loop impedance test (High current measurement, No trip (ATT) measurement) 4 Prospective short circuit current test (On Loop impedance function)
• RCD test
• Voltage test
• Phase rotation test 8 Earth test

The KEW 6516 tester incorporates Anti Trip Technology (ATT) which electronically bypasses RCDs when performing loop impedance tests. This saves time and money by not having to take the RCD out of the circuit during testing and is a safer procedure to follow.

With the ATT function enabled, a test of 15mA or less is applied between line & earth. It enables loop impedance measurements without tripping RCDs rated at 30mA and above.

ATT supports measurements using three wires: Line, Earth, and Neutral and also two wires: Line and Earth.

DISPLAY - Colour LCD 3.5 inches dot matrix.

ATT - Anti-Trip Technology (with 2 & 3 wire) for no trip LOOP L-PE testing on all RCDs.

      - With 2 wire only, very useful in case of no Neutral (i.e. 3-phase motor lines).

LOOP - High test current range of 2Ω with 0.001Ω resolution.

         - Zs Limit compares the values required by Electrical Installations Standard with measured results.

RCD - Type AC, A, F, B(General & Selective), EV and Variable RCDs.

        - Single and Auto test, Ramp test and Contact voltage.

EARTH - Earth resistance test 2 and 3 wires with all accessories included.

INSULATION - Resistance test 100, 250, 500 & 1000V with auto discharge voltage.

CONTINUITY - Continuity test at 200mA or 15mA with selectable buzzer for fast judgment.

PHASE - On 3-phase lines with clear indication of the sequence on the display.

ROTATIONVOLTS - TRMS Voltage measurements 2-600V, Mains Frequency.

HELP - Display shows how to connect the instrument according to the function selected.

SPD - Surge Protection Device test, for SPD that uses varistor.

PAT - Portable Appliance Tester function, for Insulation and Protective conductor resistance test

Bluetooth - Communication by "KEW CONNECT"

SAFETY - IEC 61010-1 CAT IV 300 V, CAT III 600 V. IEC 61557-1,2,3,4,5,6,7,10.
